Tipping Trailer
Product Details:
X
Product Description
Assisted by a qualified workforce and advanced manufacturing unit, we are engaged in offering a wide range of Tipping Trailer. Our offered trailer is manufactured using high quality raw material and advanced manufacturing techniques under our expert's guidance. The offered trailer is specially designed to withstand the toughest working conditions and is widely used for different warehousing and loading applications. Further, clients can avail this Tipping Trailer from us at economical prices.
Key Features:
- Precisely designed
- Sturdy construction
- Robustness
- Longer service life
Advantage
- Flexibility of unloading goods & materials by simply tripping them ; saves operating cost
- Removable & drop down door gives flexibility of loading & unloading
- Rear door drop down & vise versa.
Features
- Heavy duty frame & structured framework brings in greater strength & stability.
- World's super steel hub & taper roller bearing low maintenance cost.
- Reliable & heavy duty hydraulic cylinder that works under varying work condition.
- Durable hitech forging transportation hitch manufactured by forging.
Technical Specifications
| Description | Capacity: 5 Ton | Capacity: 10 Ton |
| Dimension | 3000x1830x610mm (LxWxH) | 3350x1830x610mm (LxWxH) |
| First Chassis | 150x75mm M.S. Channel | 200x75mm M.S. Channel |
| Second Chassis | 100x50mm M.S. Channel | 125x65mm M.S.Channel |
| Support Channel | 75x40mm M.S.Channel | 75x40mm M.S.Channel |
| Floor Platform | 3mm thickness | 4mm thickness |
| Side wall | 2mm thickness corrugated/plan | 2mm thickness corrugated/plan |
| Front Door | Bolted for easy removable | Bolted for easy removable |
| Side and Rear Doors | Two side doors and one rear door. Both drop down and removable | Two side doors and one rear door. Both drop down and removable |
| Wheel rim | Heavy duty double plate (Folding) | Heavy duty double plate (Folding) |
| No. of tyres | 2 nos.of size 7.50x16 (9.00x16 optional) | 2 nos.of size 7.50x16 (9.00x16 optional) |
| No. of Axle | One | One |
| Painting | One cot red oxide and two cot PU paint | One cot red oxide and two cot PU paint |
| Hydraulic Jack (for tipping) | 10 ton capacity heavy duty double stage | 10 ton capacity heavy duty double stage |
| Hitch Beam | 125x125mm square | 125x125mm square |
| Hitch | Forging for easy transportation | Forging for easy transportation |
| Axle | 75mm square (waterproof) | 85mm square (waterproof) |
| Axle Bearing | Taper roller | Taper roller |
| Hub | Super steel | Super steel |
| Required Power (HP) | 45 HP and Above | 55 HP and Above |
