Mounted Disc Harrow

Mounted Disc Harrow

Product Details:

X

Product Description

Mounted Disc Harrow

We are an eminent manufacturer, exporter and supplier of high performing Mounted Disc Harrow (Supreme Model). Our offered disc harrow is provided with row of sharp metal disks settled on the edge or at an angle on one or more axles and is extensively used in agriculture for increasing ploughing or smoothing the soil. The offered disc harrow is manufactured using superior quality raw material under the guidance of our adept professionals. Our offered disc harrow is tested by our quality analysts to ensure its flawlessness. Further, it is available in different specifications to meet the diverse needs of our clients. Offered Mounted Disc Harrow (Supreme Model) can be purchased from us at industry leading prices.

Key Features:

  • Durability
  • Robust construction
  • Non-interrupted performance
  • Low maintenance
  • High quality Boron steel discs.
  • Tillage depth of the harrow is 1500mm
  • Easily transportable- as it gets easily attached and mounted.
  • Maintenance is easily but need to be scheduled

ADVANTAGE

  • The MODERN MOUNTED Heavy Duty Tandem Disc Harrow used in open farm workings for the
  • superficial ploughing, for the shatter of clods, preparation of soil for sowing, burial of organic substances & remains.
  • To air the soil and to eliminate the weeds
  • For breaking the roots
  • It can be used in light and medium soil.

Technical Specifications

Description

8x8

9x9

10x10

Frame

Square Box Frame

Square Box Frame

Square Box Frame

Gang Bolt

32mm Central square solid bar with split Gangs

32mm Central square solid bar with split gangs

32mm Central square solid bar with split gangs

Length

1875mm

1875mm

1875mm

Width

1875mm

2100mm

2325mm

No. of Discs

16

18

20

Types of Disc

Notched (Front/Rear) plane optional

Notched (Front/Rear) plane optional

Notched (Front/Rear) plane optional

Disc Diameter

560mm/610mm (op) Boron Steel

560mm/610mm (op) Boron Steel

560mm/610mm (op) Boron Steel

Width of Cut

1775mm

2000mm

2250mm

Distance between Discs

225mm

225mm

225mm

Bearing Hubs

8 with Taper Roller Bearing

8 with Taper Roller Bearing

8 with Taper Roller Bearing

All over height

1100mm

1100mm

1100mm

Required Power HP

45 HP and Above

50 HP and Above

55 HP and Above

Approx.Weight

580 kg

610 kg

640 kg
